Tractor Mounted Water Well Hydraulic Crawler Drilling Rig 100m 800m

Tractor Mounted Water Well Hydraulic Crawler Drilling Rig 100m 800m
Tractor Mounted Water Well Hydraulic Crawler Drilling Rig 100m 800m Tractor Mounted Water Well Hydraulic Crawler Drilling Rig 100m 800m Tractor Mounted Water Well Hydraulic Crawler Drilling Rig 100m 800m Tractor Mounted Water Well Hydraulic Crawler Drilling Rig 100m 800m

Large Image :  Tractor Mounted Water Well Hydraulic Crawler Drilling Rig 100m 800m

Product Details:
Brand Name: MEGA DRILLTECH
Payment & Shipping Terms:
Minimum Order Quantity: 1

Tractor Mounted Water Well Hydraulic Crawler Drilling Rig 100m 800m

Description
Product Name: Water Well Drilling Rig
High Light:

800m Water Well Drilling Rig

,

Tractor Mounted Crawler Drilling Rig

Water Well Drilling Rig

Product Description:

100m,180m,200m,280m,300m,350M,400m,450m,580m and up to 800m portable water well drilling machine/water well drilling rig/crawler portable water well drilling equipment/tractor mounted water well drilling rig/drilling rig for water well drilling/diesel hydraulic DTH AIR PRESS WATER WELL DRILLING RIG/trailer mounted water well-drilling rigs/truck mounted water well drilling rigs

Tractor Mounted Water Well Hydraulic Crawler Drilling Rig 100m 800m 0Tractor Mounted Water Well Hydraulic Crawler Drilling Rig 100m 800m 1Tractor Mounted Water Well Hydraulic Crawler Drilling Rig 100m 800m 2



The weight(T)
7.6
Drill pipe diameter(mm)
Φ76 Φ89
The hole diameter(mm)
140-305
Drill pipe length(m)
1.5m 2.0m 3.0m
Drilling depth(m)
280
Rig lifting force(T)
17
One-time advance length(m)
6.6
Rapid rise speed(m/min)
25
Walking speed(km/h)
2.5
Fast feeding speed(m/min)
30
Climbing angles(Max.)
30
Width of loading(m)
2.7
Equipped capacitor(kw)
75
Hoisting force of winch(T)
2
Using air pressure(MPA)
1.7-3.0
Swing torque(N.m)
4500-6000
Air consumption(m³/min)
17-31
Dimension(mm)
5900×1850×2360
Swing speed(rpm)
40-70
Equipped with hammer
Medium and high wind pressure series
The penetration efficiency(m/h)
15-35
High leg stroke(m)
1.4
