Product Details:
|
| High Light: | 260m Hydraulic Crawler Drilling Rig,ISO9001 Hydraulic Crawler Drilling Rig,260m water borehole drilling machine |
||
|---|---|---|---|
Water Welll Drilling ,Solar Drilling Rig, Small Borepile Drilling ,Micropile Drilling Machine, Water Welll Drilling
T-MDT-500 crawler water well drilling rig islightweight, efficient, multi-purpose drilling equipment, which can use air,foam or mud rotary for percussive drilling according to different textures. Itis widely used in industrial and agricultural water conservancy projects, suchas drilling wells, testing wells or other exploration boreholes, in particular,in drilling hole for geothermal heating it can also meet the engineering basisfor reinforcement, loose gravel drilling rock formation connected with avariety of engineering requirements.
Technical parameters
| Bore diameter(mm) | 115-300 |
| Bore depth(m) | 260 |
| Walk speed(km/h) | 0-2.5 |
| For rock(F) | 6-20 |
| Air pressure(Mpa) | 1.05-3.0 |
| nsumption(m³/min) | 16-30 |
| nce promotion(mm) | 3000 |
| Skid max angle(°) | 90 |
| Maximum height from the ground(mm) | 320 |
| peed(r/min) | 0-110 |
| Rotation torque(NM) | 4400 |
| power(T) | 8.5 |
| Cimb ability(°) | 25 |
| Dimension(L*W*H)(mm) | 5300*2100*2700 |
| weight(Kg) | 6700 |
