Agricultural Water Well Drilling Rig Machine Multifunctional

Agricultural Water Well Drilling Rig Machine Multifunctional
Agricultural Water Well Drilling Rig Machine Multifunctional Agricultural Water Well Drilling Rig Machine Multifunctional Agricultural Water Well Drilling Rig Machine Multifunctional Agricultural Water Well Drilling Rig Machine Multifunctional Agricultural Water Well Drilling Rig Machine Multifunctional Agricultural Water Well Drilling Rig Machine Multifunctional Agricultural Water Well Drilling Rig Machine Multifunctional

Large Image :  Agricultural Water Well Drilling Rig Machine Multifunctional

Product Details:
Brand Name: MEGA DRILLTECH

Agricultural Water Well Drilling Rig Machine Multifunctional

Description
Product Name: Water Well Drilling Rig Machine
High Light:

Agricultural Drilling Rig Machine

,

Multifunctional Drilling Rig Machine

Water Well Drilling Rig Machine

Product Description:

1, it is a high efficiency and multi-functional down the hole water well drilling equipment, It can be used to drill water well, agrecultural irrigation well, geothermal well and other type well holes. It is sepcial suitable for mountain area and rock stratum water sourcing project.

2, This machine can drill in different stratum, The maximum bore diameter can be 350mm.

3, This machine adopts big torque hydraulic motor for power head and brand diesel, big diameter hydraulic cylinders for the hydraulic control system. The brand diesel is protected by 2 levels air filtration systems and also can directly use the clean air from the air compressor.

4,Unique bump set design and centralize controlled operation system is easy to maintain and convenient for machine operation.

5,This machine adopts excavator crawler chassis and make the machine a high off-road performance, It also can be mounted on a truck to make it more maneuverability.

6, Two gears rotation and feeding speed makes it work in soil and rock layers.

Agricultural Water Well Drilling Rig Machine Multifunctional 0Agricultural Water Well Drilling Rig Machine Multifunctional 1Agricultural Water Well Drilling Rig Machine Multifunctional 2Agricultural Water Well Drilling Rig Machine Multifunctional 3

Specification:



The weight(T)
9.4
Drill pipe diameter(mm)
Φ89 Φ102
The hole diameter(mm)
140-350
Drill pipe length(m)
1.5m 2.0m 3.0m 6.0m
Drilling depth(m)
450
Rig lifting force(T)
25
One-time advance length(m)
6.6
Rapid rise speed(m/min)
20
Walking speed(km/h)
2.5
Fast feeding speed(m/min)
40
Climbing angles(Max.)
30
Width of loading(m)
2.8
Equipped capacitor(kw)
103
Hoisting force of winch(T)
2
Using air pressure(MPA)
1.7-3.5
Swing torque(N.m)
7000-9500
Air consumption(m³/min)
17-36
Dimension(mm)
5950×2100×2600
Swing speed(rpm)
50-135
Equipped with hammer
Medium and high wind pressure series
The penetration efficiency(m/h)
15-35
High leg stroke(m)
1.6
