Product Details:
|
| Highlight: | Mountain Areas Well Drilling Rig,200m Well Drilling Rig |
||
|---|---|---|---|
Product Description of FYX180 Water Well Drilling Rig Equipment:
Cheap Price Hydraulic Portable 180m/200m/280m/350m/450m/580m/800m Water Well Drilling Rig Machine for Sale is suitable for drilling works such as water well drilling, general exploration, geophysical exploration, street and building exploration, blasting hole drilling and so on.
1, With automatic oil supply mechanism, improving drilling efficiency, reducing labor intensity.
2, The use of ball clamping mechanism instead of chuck, can achieve non-stop inverted bar, be easy to operate, safe and reliable.
3, With a hole-bottom pressure gauge, easy to control the situation in hole.
4, Compact structure,centralized handle, small footprint, light weight, strong decomposition, easy to move. Suitable for plain and mountain areas.
Specification of FYX180 Water Well Drilling Rig Equipment:
| The weight | 4.5T |
| Dimension | 3950*1630*2250mm |
| The hole diameter | 140-254mm |
| Drilling depth | 180m |
| One-time advance length | 3.3m |
| Walking speed | 2.5KM/H |
| Climbing angles | 30 |
| Power | 55kw |
| Using air pressure | 1.7-2.5MPA |
| Air consumption | 17-31 |
| Drill pipe length | 1.5m 2.0m 3.0m |
| Drill pipe diameter | 76mm,89mm |
| Rig lifting force | 12T |
| Swing speed | 45-65rpm |
| Swing torque | 3200-4600N.m |
