280M Cheap Water Well Drilling Rig

280M Cheap Water Well Drilling Rig
280M Cheap Water Well Drilling Rig 280M Cheap Water Well Drilling Rig 280M Cheap Water Well Drilling Rig 280M Cheap Water Well Drilling Rig 280M Cheap Water Well Drilling Rig

Large Image :  280M Cheap Water Well Drilling Rig

Product Details:
Brand Name: MEGA DRILLTECH
Payment & Shipping Terms:
Minimum Order Quantity: 1

280M Cheap Water Well Drilling Rig

Description

Description of 280M Cheap Water Well Drilling Rig:

280M Cheap Water Well Drilling Rig is widely used for water well drilling, geothermal air-conditioning venture and other boreholes, especially relevant to mountain area and rock formation water engineering. Much higher environment friendly than the traditional mud rotary drill rigs, creating the widespread economic benefit for users. Especially remedy problems to drill hard rocks that the usual rotary drilling rig meet and it should work with air compressor. When drill soft underground formation, it is OK to use mud rotary drilling, and there is mud drilling swivel system.



Features of 280M Cheap Water Well Drilling Rig:

1. Guangxi Yuchai diesel engine( cummins engine for option), strong power;

2. The patented design of the composite boom, double cylinder lift, long trip, high tonnage

3. Each rig is equipped with stoppers to raise the big arm to protect the safety of the cylinder.

4. Rig chassis: professional excavator chassis, durable, large bearing capacity, chain width, hard road damage;

5. Parallel transmission design, separate oil pump, sufficient power supply, reasonable distribution, unique design of hydraulic system

6. The traveling motor is equipped with a gear box, which is durable and has a long service life.

7. Dustfall device: Effectively reduce dust pollution damage, aiming at pit and tunnel construction

8. Fast distribution valve: speed three gear up to 70 rpm, basic dual-use water vapor function

280M Cheap Water Well Drilling Rig 0280M Cheap Water Well Drilling Rig 1280M Cheap Water Well Drilling Rig 2

Specification of 280M Cheap Water Well Drilling Rig:

The weight(T)
7.6
Drill pipe diameter(mm)
Φ76 Φ89
The hole diameter(mm)
140-305
Drill pipe length(m)
1.5m 2.0m 3.0m
Drilling depth(m)
280
Rig lifting force(T)
17
One-time advance length(m)
6.6
Rapid rise speed(m/min)
25
Walking speed(km/h)
2.5
Fast feeding speed(m/min)
30
Climbing angles(Max.)
30
Width of loading(m)
2.7
Equipped capacitor(kw)
75
Hoisting force of winch(T)
2
Using air pressure(MPA)
1.7-3.0
Swing torque(N.m)
4500-6000
Air consumption(m³/min)
17-31
Dimension(mm)
5900×1850×2360
Swing speed(rpm)
40-70
Equipped with hammer
Medium and high wind pressure series
The penetration efficiency(m/h)
15-35
High leg stroke(m)
1.4
