Product Details:
|
Product Description:
The overall layout is reasonable, and the traction or all-ground chassis is used for transportation, with good maneuverability. It is very flexible on difficult roads, and can be widely used in hydrological well resource exploration, coalbed methane, shallow shale gas, geothermal and other fields, and can also be used in coal mine gas mining and salvage work.
Product parameters:
| Machine weight(T) | 12 |
| Drilling hold diameter(M) | 140-350 |
| Drilling depth (M) | 580 |
| Once-time advance length(M) | 6.6 |
| Walking speed (km/h) | 2.5 |
| Max.climbing capacity | 30 |
| Main motor power (kw) | 132 |
| Using air pressure (mpa) | 1.7-3.5 |
| Air consumption (m3/min) | 17-42 |
| Drill pipe diameter (mm) | 102/108/114 |
| Drill pipe length (m) | 1.5/2/3/6 |
| Rig lifting force(N) | 28 |
| Dimension(mm) | 6200x2200x2650 |
| Swing torque (N.M) | 8500-11000 |
