Mobile Drilling Rig

Mobile Drilling Rig
Mobile Drilling Rig Mobile Drilling Rig Mobile Drilling Rig Mobile Drilling Rig Mobile Drilling Rig

Large Image :  Mobile Drilling Rig

Product Details:
Brand Name: MEGA DRILLTECH

Mobile Drilling Rig

Description

Product Description:

1. Rotation adopts double motor pressure , hightorque , small dimension rotary velocity can be adjusted
2. It adopts triple equipment pump ,make positive oil pump long lasting and reliable
3. Combined platform ,nice diagram , equiped with peda l,easy to operate.
4. It is equiped with grasp ,auxiliary radiator ,it fits for the place of excessive altitude ,with bloodless climate.
5. Travel motor with German technology; excessive torque and hiking potential ,low failure price

Mobile Drilling Rig 0Mobile Drilling Rig 1



product specification:

Technical Parameters of 92KW Hydraulic Water Well Drilling Rig
The weight 9.2T
Dimension 6000*2000*2550mm
The hole diameter 140-325mm
Drilling depth 350m
One-time advance length 6.6m
Walking speed 2.5KM/H
Climbing angles 30
Power 92KW
Using air pressure 1.7-3.4MPA
Air consumption 17-36
Drill pipe length 1.5m 2.0m 3.0m 6.0m
Drill pipe diameter 89mm,102mm,
Rig lifting force 22T
Swing speed 66-135rpm
Swing torque 6200-8500N.m
