Borehole Drilling Machine

Borehole Drilling Machine
Borehole Drilling Machine Borehole Drilling Machine Borehole Drilling Machine

Large Image :  Borehole Drilling Machine

Product Details:
Brand Name: MEGA DRILLTECH
Payment & Shipping Terms:
Minimum Order Quantity: 1

Borehole Drilling Machine

Description

Product Description:

self-propelled pneumatic drilling rig Features:
1. The chassis of the drilling rig adopts a professional taking walks motor with a discount box, which has a longer life;
2. The gearbox is forged in one piece, with dual motors offering superior power, large torque, greater durable, and low protection costs;
3. The use of expert excavator chassis, sturdy and durable, giant load-bearing, vast chain plate, little harm to tough roads;
4. Each hydraulic oil pipe is protected with a thick shielding jacket to make the provider lifestyles of the oil pipe longer;

Borehole Drilling Machine 0Borehole Drilling Machine 1



The weight(T)
6.5
Drill pipe diameter(mm)
Φ76 Φ89
The hole diameter(mm)
140-305
Drill pipe length(m)
1.5m 2.0m 3.0m
Drilling depth(m)
260
Rig lifting force(T)
15
One-time advance length(m)
3.3
Rapid rise speed(m/min)
24
Walking speed(km/h)
2.5
Fast feeding speed(m/min)
28
Climbing angles(Max.)
30
Width of loading(m)
2.73
Equipped capacitor(kw)
70
Hoisting force of winch(T)
1.5
Using air pressure(MPA)
1.7-3.0
Swing torque(N.m)
4000-5300
Air consumption(m³/min)
17-31
Dimension(mm)
4000×1850×2300
Swing speed(rpm)
45-70
Equipped with hammer
Medium and high wind pressure series
The penetration efficiency(m/h)
10-35
High leg stroke(m)
1.4
