MDT-320 Three Piston Drilling Mud Pump Triplex Mud Pump For Soil Investigation

MDT-320 Three Piston Drilling Mud Pump Triplex Mud Pump For Soil Investigation
MDT-320 Three Piston Drilling Mud Pump Triplex Mud Pump For Soil Investigation

Large Image :  MDT-320 Three Piston Drilling Mud Pump Triplex Mud Pump For Soil Investigation

Product Details:
Brand Name: MEGA DRILLTECH
Model Number: MDT-320
Payment & Shipping Terms:
Payment Terms: T/T, T/T
Contact Now

MDT-320 Three Piston Drilling Mud Pump Triplex Mud Pump For Soil Investigation

Description
Highlight:

MDT-320 Drilling Mud Pump

,

Three Piston Drilling Mud Pump

,

Three Piston Triplex mud pump

Three Piston Drilling Mud Pump For Soil Testing, Piston Pump For Soil Investigation Drilling

Triplex reciprocating plunger pump, for drilling 0-2500m, max pressure 10Mpa, max flow 320L/min.



MDT-320 is a triplex(3-cylinders) reciprocating plunger pump, has two cylinder diameter and four gear speed which bringgs 8 different flow for option. It can be used for hydraulic impact drilling pump within depth 1000m, also can be used for auger drilling, turbo drilling within 1500m, as well as supplying mud for conventional core drilling within 2500 m. It has reliable performance, long life, with small and compact dimension. The pump is an ideal product for teological exploration as well as civel engineering drilling work.





Type
 Horizontal three cylinder single action reciprocating plunger pump
Travel 110
Cylinder Diameter(mm) 80 60
Pump Speed(min-1) 214 153 109 78 214 153 109 78
Displacement(L/min) 320 230 165 118 180 130 92 66
Pressure(MPa) 4 5 6 8 6 8 9 10
Volumetric Efficiency(%) 90
Total Efficiency(%) 78
Power Needed(kw) 30
Large Belt Nodal Diameter(mm) φ480(C×5) φ480(C×5)
Speed Input(r/min) 535
Suction Height(m) 2.5
Suction Pipe Diameter(mm) φ76
Discharging Pipe Diameter(mm) φ51
Dimension(LxWxH)(mm) 1280×855×720
Single Pump(Without Engine and Air Chamber)
1905×1100×1200
Entire Pump( Without Engine and Air Chamber)
Weight(kg) 650 Single Pump(Without Engine and Air Chamber)
1000 Entire Pump( Without Engine and Air Chamber)
