| Highlight: | horizontal mud mixing pump,Triplex mud mixing pump,Triplex industrial sludge pump |
||
|---|---|---|---|
Triplex Drilling Mud Pump For Soil Testing, Piston Pump For Soil Investigation Drilling
The MDT-160 mud pump is a horizontal ,three-cylinder single-acting ,reciprocal piston pump, It is mainly used to supply flushing fluid to the drilling well in engineering drill’s bedrock drilling or exploratory drilling . Its shell is A-alloy, so it is lightweight. The pump has two speed and is easily operation.
Basic Data:
| Type | Horizontal ,three-cylindersingle-acting ,reciprocal piston pump |
| Liner Dia (mm) | 65 |
| Stroke | 70 |
| Reciprocate Times (times/ minute) | 245 190 |
| Displacement (liter/min) | 160 120 |
| Pressure | 1.5 2.0 |
| Input Power | 5.88 |
| Suction Pipe Dia(mm) | 51 |
| Discharge Pipe Dia(mm) | 25 |
| V-shaped belts (B*3) | 310(mm) |
| Input Speed | 754 (rotations/min) |
| Mass (including the engine) | 200kg |
| Dimensions | 1200*550*580 (mm) |
