1500r/Min Horizontal Reciprocating Drilling Mud Pump For Soil Investigation

1500r/Min Horizontal Reciprocating Drilling Mud Pump For Soil Investigation
1500r/Min Horizontal Reciprocating Drilling Mud Pump For Soil Investigation

Large Image :  1500r/Min Horizontal Reciprocating Drilling Mud Pump For Soil Investigation

Product Details:
Brand Name: MEGA DRILLTECH
Model Number: MDT-150
Payment & Shipping Terms:
Payment Terms: T/T

1500r/Min Horizontal Reciprocating Drilling Mud Pump For Soil Investigation

Description
Highlight:

1500r/min Drilling Mud Pump

,

Horizontal Reciprocating Drilling Mud Pump

,

1500r/min reciprocating mud pump

Three Piston Drilling Mud Pump For Soil Testing, Piston Pump For Soil Investigation Drilling

horizontal ,three-cylinder single-acting ,reciprocal piston pump, used to supply flushing fluid to the drilling well in enginee


The pump is one of the principle equipment for geological drilling, it delivers the enough volume circulating mud water of desired characteristic under pressure into the well to bring the rook clastic up to the ground, to cool the drill bit to lubricate the drill tool and to protect the wall of the well, so the function of mud pump affect the efficiency of drilling and safety in production direct. BW-150 Mud pump is a horizontal, triplex, single acting reciprocating piston pump, which has eight speeds to get various output volume. It’s capable of delivering circulating mud water required in small bore core drill, ling 1000-1500 meter deep with diamond bits, the pump can be driven by electromotor or diesel engine according to the requirement of the customer in order.



MDT-150

Horizontal, Three-cylinder single-acting, reciprocal piston pump
stroke 70mm
Liner Dia 70mm
Gears I II III IV I II III IV
Reciprocate Times(Times/Minute) 222 130 86 57 183 107 71 47
Displacement(liter/minute) 150 90 58 38 125 72 47 32
Pressure(MPa) 1.8 3.2 4.8 7 2.3 4 6 7
Power 7.5 Kw
Input speed 1500 r/min
Suction water height 2.5 m
Suction Pipe Dia 51 mm
Discharge Pipe Dia 32 mm
Dimensions 1840x795x995
Weight 516 Kg
