MDT-Q160 mud pump is a horizontal ,single-cylinder double-acting ,reciprocal piston pump . This pump uses the crankshaft and connecting. The main driven systrm that well-oiled and in high durablicity is in closed position. The suction valve and the drainage valves are ball check valve. The valves’open and close are reliable and durability. The pump has the advantages of high-duty,moderate pressure, simple structure, easy to maintain, small and light, and so on. It is mainly used for suppling the washing liquid in the drilling of engineering geology. The liquid that the sand-content is less than 5% or non-corrosive effect to the metal and the rubber parts can be supplied by the pump.
Basic Data:
| Type | horizontal ,single-cylinder double-acting ,reciprocal piston pump | |
| Liner Dia (mm) | 95 | |
| Stroke | 90 | |
| Reciprocate Times (t/ min) | 146 | |
| Displacement (liter/min) | 160 | |
| Pressure | 1.5 | |
| Suction Pipe Dia(mm) | 45 | |
| Discharge Pipe Dia(mm) | 25 | |
| Power | Diesel Engine | Motor |
| Input Power(KW0 | 5.15 | 5.5 |
| Ratoting Speed(rpm) | 2600 | 1440 |
| Mass(including the engine) | 140kg | |
| Dimensions (mm) | 1200*900*800 | |
