Engineering Hydraulic Rotary Drilling Rig 70rpm Angle Adjustable

Engineering Hydraulic Rotary Drilling Rig 70rpm Angle Adjustable
Engineering Hydraulic Rotary Drilling Rig 70rpm Angle Adjustable Engineering Hydraulic Rotary Drilling Rig 70rpm Angle Adjustable

Large Image :  Engineering Hydraulic Rotary Drilling Rig 70rpm Angle Adjustable

Product Details:
Brand Name: MEGA DRILLTECH
Model Number: MDT70

Engineering Hydraulic Rotary Drilling Rig 70rpm Angle Adjustable

Description
High Light:

70rpm hydraulic rotary drilling rig

,

Engineering hydraulic rotary drilling rig

,

70rpm portable borehole drilling machine

Engineering Hydraulic Rotary Drilling Rig 70rpm Angle Adjustable



Anchoring Drilling Machine Engineering Anchoring Drilling Rig For Grouting,Anchor Drilling Machine



Anchor drilling machine mainly used in geological hazard prevention and control of the landslide and the displacement of anchorage and control structures of dangerous rock mass high slope rock mass of anchorage engineering, such as urban can also be used for deep foundation pit, the foundation reinforcement holes, blasting holes and drain hole drilling. With simple structure, light weight, disintegration of relocation transportation convenience; Adopts full hydraulic pressure control, convenient operation; A second gear rotary speed and torque, can be selected according to actual needs, strong adaptability.



1.Three phase asynchronous electric motor and double connect gear oil pump provide power for drilling rig

2.It adopts hydro-cylinder feeding pattern with compact structure, big lifting force and good stability

3.The radiator can reduce the oil temperature efficiently to avoid hydraulic oil from changing to low viscosity or destroyed because of the very high temperature of oil.

4.The up and down hydro-cylinder can adjust the angle of guide rail fast to satisfy drilling requirements from different angles.



Technical parameter



Model MDT40 MDTG50 MDT70
Drilling depth 10-60m 25-70m 35-80m
Drilling diameter 90-180mm 90-165mm 90-200mm
Hole angle 0-90° 0-90° 0-90°
Drilling rod diameter 76 x 1500mm 76 x 1500mm

89 x 1500mm

76 x 1500mm

89 x 1500mm

Output rotay speed 90rpm 70rpm 70rpm
Rated output torque 2400N.m 2500N.m 3900N.m
Power head max stroke 1800mm 1800mm 1800mm
Max lifting force 25kn 30kn 35kn
Electric power 4KW 22kw 22kw
Dimension 2800*800*1400 3000*780*1360 3100*1000*1500mm
weight 1000KG 1260kg 1460kg
