Product Details:
|
| Highlight: | 55KN Anchor Drilling Rig,50 meter Anchor Drilling Rig,50 meter rotary drilling machine |
||
|---|---|---|---|
50 Meter 55KN Anchor Drilling Rig Rotary Drilling Machine blue
Anchoring Drilling Machine, Rotary Borehole Drilling Machine For Sale
| Model | MDT-S50 | |
| Winch | hole depth(m) | 50 |
| hole diameter(mm) | 50~110 | |
| Rotary speed(rpm) | 30;60 | |
| Capacity | ||
| Drill Head Max. Thrust Force | ||
| Torque(Nm) | 3240;1620 | |
| Frequency(CPM) | 4000 | |
| Vibrator force(KN) | 38 | |
| Weight(kg) | 359 | |
| Winch | Pulling force(KN) | 55KN |
| Diameter of wire rope (mm*m) | 0.45m/s | |
| Feeding System | Pressure(KN) | 20 |
| Pressure speed(m/min) | 12.2;24.4 | |
| Pulling force(KN) | 50 | |
| Pulling speed (m/min) | 7.4;14.8 | |
| Feeding Stroke(mm) | 2300 | |
| Diesepower | Power(KW) | |
| 46 | ||
| Rotary speed(rpm) | 2200 | |
| Approx. weight | about 3.8 | |
| Outside dimension | L*W*H(mm) Transportation |
|
| 5600X1450X2200 | ||
| L*W*H(mm)Working | 3400X1450X5600 | |
