Hydraulic Geotechnical Anchor Bolt Drilling Machine 80m Depth

Hydraulic Geotechnical Anchor Bolt Drilling Machine 80m Depth
Hydraulic Geotechnical Anchor Bolt Drilling Machine 80m Depth Hydraulic Geotechnical Anchor Bolt Drilling Machine 80m Depth Hydraulic Geotechnical Anchor Bolt Drilling Machine 80m Depth Hydraulic Geotechnical Anchor Bolt Drilling Machine 80m Depth

Large Image :  Hydraulic Geotechnical Anchor Bolt Drilling Machine 80m Depth

Product Details:
Brand Name: MEGA DRILLTECH
Model Number: MDT-80
Payment & Shipping Terms:
Payment Terms: T/T

Hydraulic Geotechnical Anchor Bolt Drilling Machine 80m Depth

Description
High Light:

80m anchor bolt drilling machine

,

Hydraulic anchor bolt drilling machine

,

80m rotary boring machine

Hydraulic Geotechnical Anchor Bolt Drilling Machine 80m Depth​



Hydraulic Rock Anchor Drilling Rig, Anchor Drilling Machine, Slope Protection Drilling



Model MDT-80
Borehole Depth 80m
Borehole Diameter Φ100-Φ209mm
Recommended Drill Rod Φ89*1.5m; Φ114*1.5m
Drill Angle 0~120°
Drill Head Rotary Speed(FR/RE) 5~180rpm
Max Output Torque of Power Head 3500Nm
Drill Head Feeding Stroke 1800mm/1200mm
Drill Head Max. Lifting Force 45KN
Drill Head Max. Thrust Force 30KN
Engine Model Electromotor:Y200L-4
(Optional-Diesel Enigne)
Engine Power 30KW
  3400*1000*1500mm
Overall Dimension(Drill Reduce Type)
Bigger Part Weight,appx. 200kg
Drilling Rig Weight,appx. 1500kg
(not include engine)
