Product Details:
Brand Name: MEGA DRILL TECH
Model Number: MDT550
Payment & Shipping Terms:
Payment Terms: T/T

350m Depth Multifunction Micropile Drilling Machine High Flexibility

Description
High Light:

350m Micropile Drilling Machine

,

multifunction Micropile Drilling Machine

,

350m blast hole drilling machine

Water Welll Drilling ,Solar Drilling Rig, Small Borepile Drilling ,Micropile Drilling Machine, Water Welll Drilling

MDT550 track-type waterwell drilling rig is lightweight, efficient, multi-purpose drilling equipment,which can use air, foam or mud rotary for percussive drilling according todifferent textures. It is widely used in industrial and agricultural waterconservancy projects, such as drilling wells, testing wells or other explorationboreholes, in particular, in drilling hole for geothermal heating it can alsomeet the engineering basis for reinforcement, loose gravel drilling rockformation connected with a variety of engineering requirements.





Technical parameters

Bore diameter(mm) 115-350
Bore depth(m) 350
Walk speed(km/h) 0-2.5
For rock(F) 6-20
Air pressure(Mpa) 1.05-3.5
Air consumption(m³/min) 16-40
Once promotion(mm) 3600
Skid max angle(°) 90
Maximum height from the ground(mm) 320
Rotation Speed(r/min) 0-110
Rotation torque(NM) 5600
Lifting power(T) 15
Lifting speed(m/min) 27
Climb ability(°) 25
Dimension(L*W*H)(mm) 6500*2100*2600
weight(Kg) 9400
