30m Depth Hydraulic Crawler Drilling Rig DTH Drilling Machine

30m Depth Hydraulic Crawler Drilling Rig DTH Drilling Machine
30m Depth Hydraulic Crawler Drilling Rig DTH Drilling Machine 30m Depth Hydraulic Crawler Drilling Rig DTH Drilling Machine 30m Depth Hydraulic Crawler Drilling Rig DTH Drilling Machine

Large Image :  30m Depth Hydraulic Crawler Drilling Rig DTH Drilling Machine

Product Details:
Brand Name: MEGA DRILLTECH
Model Number: MDT100Y

30m Depth Hydraulic Crawler Drilling Rig DTH Drilling Machine

Description
High Light:

30m Hydraulic Crawler Drilling Rig

,

DTH Hydraulic Crawler Drilling Rig

,

Crawler DTH drilling machine

MDT100Y DTH Drilling Rig



MDT100Y Fcrawler hydraulic drilling rig, adopts new type hydraulic rotary motor, hashigh rotary speed, large torque and low failure rate. This rig has low airconsumption, convenient for shifting holes, uses air filter and oil filtertotalthree-stage filters to reduceengine wearing , increase working life of the diesel engine. The rig structureis compact, the minimum moving radius is 2.8m, and the skid mast has compensationfunction. when drilling, the skid mast supported on the ground that guarantee good drilling stability.

The drilling rigis mainly capable for open mining, water conservancy, power plants, roadbuilding and other rock blasting holes drilling .



Technical parameters



Bore diameter(mm)90—130
Bore depth(m)30
Walk speed(km/h) 2
Once promotion(mm)2000
Grade ability (°)30
Air pressure(Mpa)0.7—1.4
Chassis ground clearance(mm) 260
Air consumption(m³/min) 7—15
Skid pitch(°)100
Host Power (Kw)33
Skid tilt swing (°)L35,R10
For rock(F)6—20
Skid compensation(mm) 900
Dimension(L*W*H)(mm)4300*2130*2160
Weight(Kg)2900
