Underground Portable Borewell Drilling Machine Yellow 480 Meter
Tunnel Dilling Machine,UX800 Underground Drill Rig,
| Depth(BQ/NQ/ HQ) | 800m / 620m / 480m |
| Rod size | A-H |
| Torque(max.) | 1080 Nm |
| Speed(max.) | 1640 rpm |
| Feed & pull force | 67KN |
| Feed travel | 1.8m |
| Max. rod size | 89mm |
| Bore (without jaws) | 102mm |
| Bore (without covers) | 170mm |
| Axial holding force | 45kN |
| Axial holding force(TC) | 90kN |
| Wireline capacity | 1000m x 4.75mm |
| Line pull | Bare drum 3.6kN, full drum 9.7kN |
| Line speed | Bare drum 1.8m/s, Full drum 4.8m/s |
The UX800 is an underground type of coring drill rig for drilling medium to deep holes, and the control panel is pilot-hydraulic-control design, Operation is flexible and comfortable, high production efficiency The UX800 grasps the international most advanced design idea and process standards, a number of technical indicators reached the industry leading. The rotation unit is compact and modular design ,it has enough torque reserve and wide RPM range. The integrated gearbox is two-speed and fully variable-control .It can effectively deal with the challenge of complex formation drilling technology. The rod holder, which is fully synchronized with the chuck, is operated by a hydraulic cylinder (opening) and a long life Nitrogen spring (closing) ensuring high clamping force and quick closing action as well as improved control and decreased service needs. The UX800 rig has a drill capacity of NQ 600 m(BQ 800m), and this flexible drilling rig can handle up to 3 m and 1.5 m core barrels.
UX800 Underground Drill Rig
- The drill is compact and modular design
- The control panel is pilot-hydraulic-control design equipped with user-friendly interface and monitoring gauges.
- With the use of a hydraulic-operated positioner and a fast calibrating turntable, the drill is easy for set up and capable of drilling holes in all angles.
- The rod holder, which is fully synchronized with the chuck, is operated by a hydraulic cylinder (opening) and a long life Nitrogen spring (closing)
