MDT-M800 87kw Portable Core Drilling Machine 1300rpm Heavy Duty

MDT-M800 87kw Portable Core Drilling Machine 1300rpm Heavy Duty​

M800 Full Hydraulic Portable Core Drill.

- The single engine power unit with strong and sufficient power reserve.

- A perfect balance of light weight and work efficiency on the plateau and grassland.

- Tailored to enhance plateau adaptability.

M800 is a hydraulic portable core drill rig, in a perfect balance between light weight and high efficient work, while maintaining the modular design with the torque and drilling rate improved, it is suitable for geological or construction exploration environment.

The M800 adopts the main structure of a F800D portable core drilling rig, but the power unit is converted to a single Cummins engine, which improves the low speed torque. So it is more suitable for the areas where the trucks can be adopted on the plateau.

The M800 core drill has a compact structure, which can be arranged in the work plane of 4m X 4m to facilitate the site disassembly. After optimized design, the M800 rig's disassembly and displacement is very simple, the process can be completed in 45 minutes. The reposition can be fixed in half a shift.

The latest model of the M800 rig owns a number of industry advanced technologies: engine integrated control, easy to achieve all engine operation on the operating area;

Hydraulic control adopts advanced pressure compensation drilling technology, balanced drill string pressure, precise control of drilling pressure, making the drilling operation handy (option);

The drill pipe gripper adopts hydraulic locking linkage technology, which is safe and reliable, which can react quickly to prevent accidental release of the rod, and the rod holder with the nitrogen spring clamping device (option) can be used to further improve the safety performance;

The power head bracket adopts the external clearance adjustable mechanism, which can be used to fine-tune the drilling axis, while maintaining seamless and close contact between the mast rail surface and the sliding frame to eliminate the drilling vibration;

Excellent plateau performance, through enhanced power reserve and optimized system configuration, fully improve the plateau work adaptability.
