ISO9001 Certified 132kw Rotary Core Drilling Rig Engineering



MDT-800L Hydraulic Surface Exploration Core Drilling Rig, Wheel Type Mining Exploration Drilling Machine



MDT800L surface core drilling rig is one kind of hydraulic top drive rotary head type drilling rig which is mainly used in diameter diamond drilling of metal and nonmetal solid deposit exploration. It can be used in carbide bit core drilling. It is used to bore vertical holes as well as inclined holes, which is also applied in engineering boreholes of hydrology water wells, petroleum or gas field exploration, dike & dam cement grouting, tunnel ventilation and water draining, etc.

features

The rig takes advantage in its high rotary speed, reasonable rotary speed range, various rotary speed grades and big torque in low speed. Hence, it’s very suitable for small diameter diamond bit core drilling. Meanwhile, it can meet the requirements of large diameter carbide bit core drilling and varieties of engineering boreholes.
It has long stroke which is helpful to reduce the rod reversion frequency, avoid coring block, and improve productivity.
It has a simple structure, a light weight and is convenient to remove, so as to make the replacement process easily.
Its operation is concentrated, simple, convenient, flexible and reliable, so as to reduce the labor intensity a lot.
It needn’t be provided with a special inclined tower when drilling inclined holes. It can also realize raising two rods at one time.
It is convenient and fast to mount and install the rig. No specialized drill tower is needed to allocate which has cut the preparation time largely.
It has several choices of the chassis, such as skid / trailer / crawler mounted(as the customers’ requests)


technical specification



Borehole diameter/depth BQ 900 m / NQ 700 m / HQ 450 m
Drill angle 0~-90°
Drill head rotary speed / torque 104~139RPM ;220~295RPM ;407~543RPM ;690~1000RPM
/Max torque:4000Nm
Drill head feeding stroke 3500 mm
Drill head Max. Lifting capacity 55 kN
Drill head Max. Thrust force 108kN
Main hoist Max. Lifting capacity 71 KN
Lifting speed 40m/min
Assist hoist Max. Lifting capacity 12 KN
Lifting speed 120m/min
Diesel engine model Cummins 6BTA5.9-C180
Diesel engine power 132kw
Drill rig weight(crawler mounted) about 10000kg
