1200rpm 300m Depth Core Drilling Rig Diamond Drilling Equipment Portable

1200rpm 300m Depth Core Drilling Rig Diamond Drilling Equipment Portable
1200rpm 300m Depth Core Drilling Rig Diamond Drilling Equipment Portable
1200rpm 300m Depth Core Drilling Rig Diamond Drilling Equipment Portable 1200rpm 300m Depth Core Drilling Rig Diamond Drilling Equipment Portable 1200rpm 300m Depth Core Drilling Rig Diamond Drilling Equipment Portable

Large Image :  1200rpm 300m Depth Core Drilling Rig Diamond Drilling Equipment Portable

Product Details:
Brand Name: MEGA DRILLTECH
Model Number: MDT-300H
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: wooden case
Payment Terms: T/T

1200rpm 300m Depth Core Drilling Rig Diamond Drilling Equipment Portable

Description
Drilling Depth: 300m Engine: Kubota V1505T,33kw/3000rpm
High Light:

1200rpm Core Drilling Rig

,

300m Core Drilling Rig

,

300m diamond drilling equipment

1200rpm 300m Depth Core Drilling Rig Diamond Drilling Equipment Portable



Diamond Drilling Equipment, Portable Drilling Machine ,Crawler Moundted Drilling Machine ,Hydraulic Drilling Machine



1. Crawler is remote controlled, equipped with high quality engineering rubber track Max speed 5KM/hour, hydraulic system easy to switch between crawler and drilling machine , crawler weight 850kgs,climb angle 30° .





2. Small dimension, machine width 1250mm, length 2167mm, easy to enter the drilling site



3. Machine installed two winches, main winch and SPT winch, main winch used for mining exploration wire line drilling, SPT cathead winch used for doing SPT test for soil investigation



4.Driling capability

BTW(60)-----300m

NTW(75)-----200m

HTW(95)-----70m



5.Machine Information DATA



Engine –Kubota V1505T,33kw/3000rpm

Hydraulic system max displacement :65L/min

Hydraulic system max pressure: 210Bar

Rotary head max rotate speed: 1200rpm

Rotary head max torque: 700rpm

Feeding stroke: 0.9m/1.8m

Max lifting force:65KN

Main winch rope capacity:400m/5mm steel rope

Main winch max pull force:7200N.m

Max weight of machine module : 180kg
