Product Details:
|
| TYPE: | HQ ROD | ||
|---|---|---|---|
| Highlight: | NQ drill pipe,ISO9001 NQ drill pipe,BQ drill pipe |
||
NQ rod,AQ/BQ/NQ/HQ/PQ drill pipe/drill rod 1.5m 3m long , 10ft PQ rod,5ft PQ rod
MEGA Drilltech manufactures Wireline Drill Rods, from WLA to WLP, Parallel Threaded Drill Rods, DCDMA Sizes AW-HW, and Metric sizes 42mm to 90mm, Tapered Threaded Drill Rods, DCDMA Sizes AWY to NWY, AWJ, BWJ and S75 Drill Rods.
Q(C)series drill rod
| No. | item | length(m) | OD*thickness(mm) | grades | depth(m) |
| 1 | AQ | 1.5 | 44.5*4.8 | ZT850 | 300 |
| 2 | AQ | 3.0 | 44.5*4.8 | ZT850 | 300 |
| 3 | BQ (BC) | 1.5 | 55.7*4.8 | ZT850 | 600 |
| 4 | BQ (BC) | 3.0 | 55.7*4.8 | ZT850 | 1200 |
| 5 | NQ (NC) | 1.5 | 70.5*5.0 | ZT850 | 600 |
| 6 | NQ (NC) | 3.0 | 70.5*5.0 | ZT850 | 1200 |
| 7 | HQ (HC) | 1.5 | 89.0*5.6 | ZT850 | 600 |
| 8 | HQ (HC) | 3.0 | 89.0*5.6 | ZT850 | 1200 |
| 9 | PQ (PC) | 1.5 | 114.3*6.2 | ZT850 | 600 |
| 10 | PQ (PC) | 3.0 | 114.3*6.2 | ZT850 | 1200 |
| 11 | SQ | 1.5 | 139.7*7.1 | ZT750 | 300 |
| 12 | SQ | 3.0 | 139.7*7.1 | ZT750 | 600 |
QRHD Series drill rod
| No. | item | length(m) | OD*thickness(mm) | Grade | Depth(m) |
| QR series | |||||
| 1 | NQR | 3.0 | 70.5*5.0 | ZT850 | 1800 |
| 2 | HQR | 3.0 | 89.0*5.6 | ZT850 | 1800 |
| HD series | |||||
| 1 | NHD | 3.0 | 73.0*5.5 | ZT850 | 2400 |
| 2 | HHD | 3.0 | 91.0*5.8 | ZT850 | 2400 |
| 3 | PHD | 3.0 | 114.3*6.2 | ZT850 | 1800 |
11
