5ft 10ft Drilling Rod NQ Drill Rod Various Specification

Certification
China HUNAN MEGA DRILLTECH CO., LTD. certification
China HUNAN MEGA DRILLTECH CO., LTD. certification
I'm Online Chat Now

5ft 10ft Drilling Rod NQ Drill Rod Various Specification

5ft 10ft Drilling Rod NQ Drill Rod Various Specification
5ft 10ft Drilling Rod NQ Drill Rod Various Specification 5ft 10ft Drilling Rod NQ Drill Rod Various Specification 5ft 10ft Drilling Rod NQ Drill Rod Various Specification

Large Image :  5ft 10ft Drilling Rod NQ Drill Rod Various Specification

Product Details:
Place of Origin: CHINA
Brand Name: MEGA DRILLTECH
Certification: ISO9001
Model Number: PQ
Payment & Shipping Terms:
Payment Terms: T/T

5ft 10ft Drilling Rod NQ Drill Rod Various Specification

Description
High Light:

10ft Drilling Rod

,

5ft Drilling Rod

,

5ft NQ drill rod

AQ/BQ/NQ/HQ/PQ Drill Pipe/Drill Rod 1.5m 3m Long , 10ft PQ Rod,5ft PQ Rod



MEGA Drilltech manufactures Wireline Drill Rods, from WLA to WLP, Parallel Threaded Drill Rods, DCDMA Sizes AW-HW, and Metric sizes 42mm to 90mm, Tapered Threaded Drill Rods, DCDMA Sizes AWY to NWY, AWJ, BWJ and S75 Drill Rods.





AQ/BQ/NQ/HQ/PQ drill pipe/drill rod 1.5m 3m long hot

Q(C)series drill rod

No. item length(m) OD*thickness(mm) grades depth(m)
1 AQ 1.5 44.5*4.8 ZT850 300
2 AQ 3.0 44.5*4.8 ZT850 300
3 BQ (BC) 1.5 55.7*4.8 ZT850 600
4 BQ (BC) 3.0 55.7*4.8 ZT850 1200
5 NQ (NC) 1.5 70.5*5.0 ZT850 600
6 NQ (NC) 3.0 70.5*5.0 ZT850 1200
7 HQ (HC) 1.5 89.0*5.6 ZT850 600
8 HQ (HC) 3.0 89.0*5.6 ZT850 1200
9 PQ (PC) 1.5 114.3*6.2 ZT850 600
10 PQ (PC) 3.0 114.3*6.2 ZT850 1200
11 SQ 1.5 139.7*7.1 ZT750 300
12 SQ 3.0 139.7*7.1 ZT750 600

QRHD Series drill rod

No. item length(m) OD*thickness(mm) Grade Depth(m)
QR series
1 NQR 3.0 70.5*5.0 ZT850 1800
2 HQR 3.0 89.0*5.6 ZT850 1800
HD series
1 NHD 3.0 73.0*5.5 ZT850 2400
2 HHD 3.0 91.0*5.8 ZT850 2400
3 PHD 3.0 114.3*6.2 ZT850 1800

11
