AQ BQ NQ HQ PQ Drill Pipe Drilling Rod 1.5m 3m Length For Construction

AQ BQ NQ HQ PQ Drill Pipe Drilling Rod 1.5m 3m Length For Construction
AQ BQ NQ HQ PQ Drill Pipe Drilling Rod 1.5m 3m Length For Construction AQ BQ NQ HQ PQ Drill Pipe Drilling Rod 1.5m 3m Length For Construction AQ BQ NQ HQ PQ Drill Pipe Drilling Rod 1.5m 3m Length For Construction

Large Image :  AQ BQ NQ HQ PQ Drill Pipe Drilling Rod 1.5m 3m Length For Construction

Product Details:
Place of Origin: CHINA
Brand Name: MEGA DRILLTECH
Certification: ISO9001
Model Number: HQ rod
Payment & Shipping Terms:
Packaging Details: BUNDLE PACKING
Payment Terms: T/T, T/T

AQ BQ NQ HQ PQ Drill Pipe Drilling Rod 1.5m 3m Length For Construction

Description
TYPE: HQ ROD
High Light:

1.5m Drilling Rod

,

AQ Drilling Rod

,

1.5m PQ drill pipe

HQ rod,AQ/BQ/NQ/HQ/PQ drill pipe/drill rod 1.5m 3m long , 10ft PQ rod,5ft PQ rod



MEGA Drilltech manufactures Wireline Drill Rods, from WLA to WLP, Parallel Threaded Drill Rods, DCDMA Sizes AW-HW, and Metric sizes 42mm to 90mm, Tapered Threaded Drill Rods, DCDMA Sizes AWY to NWY, AWJ, BWJ and S75 Drill Rods.

AQ/BQ/NQ/HQ/PQ drill pipe/drill rod 1.5m 3m long hot

Q(C)series drill rod

No. item length(m) OD*thickness(mm) grades depth(m)
1 AQ 1.5 44.5*4.8 ZT850 300
2 AQ 3.0 44.5*4.8 ZT850 300
3 BQ (BC) 1.5 55.7*4.8 ZT850 600
4 BQ (BC) 3.0 55.7*4.8 ZT850 1200
5 NQ (NC) 1.5 70.5*5.0 ZT850 600
6 NQ (NC) 3.0 70.5*5.0 ZT850 1200
7 HQ (HC) 1.5 89.0*5.6 ZT850 600
8 HQ (HC) 3.0 89.0*5.6 ZT850 1200
9 PQ (PC) 1.5 114.3*6.2 ZT850 600
10 PQ (PC) 3.0 114.3*6.2 ZT850 1200
11 SQ 1.5 139.7*7.1 ZT750 300
12 SQ 3.0 139.7*7.1 ZT750 600

QRHD Series drill rod

No. item length(m) OD*thickness(mm) Grade Depth(m)
QR series
1 NQR 3.0 70.5*5.0 ZT850 1800
2 HQR 3.0 89.0*5.6 ZT850 1800
HD series
1 NHD 3.0 73.0*5.5 ZT850 2400
2 HHD 3.0 91.0*5.8 ZT850 2400
3 PHD 3.0 114.3*6.2 ZT850 1800

11
