200m Depth 90° Angle Spindle Drilling Rig For Professional Drilling

200m Depth 90° Angle Spindle Drilling Rig For Professional Drilling
200m Depth 90° Angle Spindle Drilling Rig For Professional Drilling

Large Image :  200m Depth 90° Angle Spindle Drilling Rig For Professional Drilling

Product Details:
Place of Origin: China
Brand Name: MEGA Drilltech
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: Negotiatial
Packaging Details: 1510×600×1055 mm
Delivery Time: 15~20 days
Payment Terms: T/T

200m Depth 90° Angle Spindle Drilling Rig For Professional Drilling

Material: Q345B Max. Lifting Force: 100kN
Weight: 25t Max. Torque: 25kN·m
Hoisting Speed: 0-100m/min Dimension: 11.5m*2.5m*3.2m
Control System: PLC Feeding Speed: 0-25m/min
High Light:

90deg Angle Spindle Drilling Rig


200m Depth Spindle Drilling Rig


PLC Borehole Drilling Rig

Product Description:

Spindle Drilling Rig

This spindle drilling rig is a kind of deep hole drilling apparatus, also known as a vertical drilling rig, which is designed to provide heavy duty boring machine for drilling to a maximum depth of 200 meters. It is capable of delivering a maximum pull down force of 200 kN and a maximum torque of 25 kN·m. The dimension of this spindle drilling rig is 11.5 m * 2.5 m * 3.2 m, and the rotary speed is adjustable from 0 to 120 r/min.



The drilling rig has many benefits, including reasonable technical parameters, allowing for a higher mechanization degree and lower labor strength. It also adopts the hydraulic feeding mechanism, which leads to a convenient operation and higher drilling efficiency. Furthermore, the rotary table can be removed away from the wellhead with the front frame, providing a wide operation area and allowing for various drilling ways. Additionally, the drilling rig is characterized by compact structure, smaller volume, and light weight, making it stronger disassemblable and thus more convenient for removal, assembly or repair. Finally, a transfer mechanism is equipped in transmission case, helping perform quick hole-cleaning.


Technical Parameters:

Parameter Value
Drilling Angle 90°
Material Q345B
Drilling Diameter 200-400mm
Max. Lifting Force 100kN
Weight 25t
Rotary Speed 0-120r/min
Max. Torque 25kN·m
Hoisting Speed 0-100m/min
Dimension 11.5m*2.5m*3.2m
Feeding Speed 0-25m/min
Vertical Drilling Rig High-Speed Drilling Unit
High-Torque Drilling Unit Yes


MEGA Drilltech's Spindle Bore Driller is a deep hole drilling apparatus that can be used for a variety of applications. It features a 90° drilling angle, hoisting speed of 0-100m/min, weight of 25t, a 25kN·m max torque, and PLC control system. It is designed to provide a reliable, precise and efficient drilling solution, making it perfect for both commercial and industrial use. The minimum order quantity is one unit and the packaging details are 1510×600×1055 mm. With a competitive price and fast delivery time of 15~20 days, it is an excellent choice for anyone looking for a reliable and efficient spindle bore driller.


Support and Services:

Spindle Drilling Rig Technical Support and Service

We provide technical support and service for our Spindle Drilling Rig. Our experienced technicians are available to provide assistance with installation, setup, maintenance and troubleshooting.

We offer a wide range of services, including on-site installation and setup, remote support, and preventive maintenance. Our technicians will ensure that your Spindle Drilling Rig is running smoothly and efficiently.

We also provide 24/7 technical support via phone or email. Our technicians are available to answer any questions or concerns you may have about your Spindle Drilling Rig.

We strive to ensure that our customers are fully satisfied with their purchase. If you have any issues with your Spindle Drilling Rig, please contact us and we will do our best to resolve the problem quickly and efficiently.


Packing and Shipping:

Packaging and Shipping for Spindle Drilling Rig:

  • The Spindle Drilling Rig will be shipped in a secure wood crate with a top and bottom.
  • The crate will be designed to securely hold the Spindle Drilling Rig as well as any accessories that may accompany it.
  • The crate will be sealed with a waterproof sealant to ensure the product is not damaged during shipping.
  • The crate will be labeled with the product name, model number, and shipping address.
  • The crate will then be loaded onto a shipping truck and delivered to the shipping address.
