50r/Min Micropile Drilling Machine 2 Meter Diameter For Piling Hole

50r/Min Micropile Drilling Machine 2 Meter Diameter For Piling Hole
50r/Min Micropile Drilling Machine 2 Meter Diameter For Piling Hole 50r/Min Micropile Drilling Machine 2 Meter Diameter For Piling Hole 50r/Min Micropile Drilling Machine 2 Meter Diameter For Piling Hole 50r/Min Micropile Drilling Machine 2 Meter Diameter For Piling Hole 50r/Min Micropile Drilling Machine 2 Meter Diameter For Piling Hole

Large Image :  50r/Min Micropile Drilling Machine 2 Meter Diameter For Piling Hole

Product Details:
Brand Name: MEGA DRILLTECH
Model Number: MDT-30
Payment & Shipping Terms:
Payment Terms: T/T

50r/Min Micropile Drilling Machine 2 Meter Diameter For Piling Hole

Description
High Light:

50r/min micropile drilling machine

,

2 meter micropile drilling machine

,

2 meter rotary pile drilling rig

2m diameter borepile drilling ,Rotary Piling Rigs Machine , borepile drilling machine
Feature
Flexible: the whole tonnage is small, simple operating, moving fast, convenient transition, etc features.
High returns: small investment, quick gains, economic advantages can not be replaced.
Technology patents: patent uses a unique technology to achieve a small torque but big power characteristics, thus achieve a small
machine to drill big piling hole .
Drilling depth
30m
Hole diameter
500-1600 mm

Engine
Brand
Cummins
Power
210HP (154KW)

Power Head
Torque
130 KN ·m
Rotating speed
10-50 r/min


Main Winch
Maximum lifting force
150 KN
Lifting speed
70 m/ min
Wire rope diameter
24 mm


Vice Winch
Maximum lifting force
30 KN
Lifting speed
55 m/ min
Wire rope diameter
14 mm


Pressurized Cylinder
Maximum pressure
120 KN
Max lifting speed
120 KN
stroke
2500 mm

Walk
Walk speed
5 km/h
Maximum grade
30 °
System pressure
32 Mpa
Weight
28 / 30 T
Working Radius
4.3 m
Dimensions (L * W * H)
11.5 m*3 (2.8-3.6)m*3.55m
