Three Piston Drilling Mud Pump

Three Piston Drilling Mud Pump
Three Piston Drilling Mud Pump Three Piston Drilling Mud Pump Three Piston Drilling Mud Pump

Large Image :  Three Piston Drilling Mud Pump

Product Details:
Brand Name: MEGA DRILLTECH
Model Number: MDT-250
Payment & Shipping Terms:
Payment Terms: T/T

Three Piston Drilling Mud Pump

Description
High Light:

Three Piston Drilling Mud Pump

,

Drilling Mud Pump Horizontal

,

15kw Reciprocating Piston Pump

horizontal ,three-cylinder single-acting ,reciprocal piston pump, used to supply flushing fluid to the drilling well in enginee


Main Technical Specifications

MDT-250
Type Horizontal, Three-cylinder single-acting, reciprocal piston pump
stroke 100 mm
Liner Dia 80mm 65mm
Gears I II III IV I II III IV
Reciprocate Times(Times/Minute) 200 116 72 42 200 116 72 42
Displacement(liter/minute) 250 145 90 52 166 96 60 35
Pressure(MPa) 2.5 4.5 6 6 4 6 7 7
Dimension rate: 85%
Efficiency 72%
Power 15 Kw
Triangular section belts B×5 410 mm
Input speed 500 r/min
Suction water height 2.5 m
Suction Pipe Dia φ76 mm
Discharge Pipe Dia φ51 mm
Dimensions 1100 × 995 × 650 mm
Weight 500
