Hydrography Anchor Drilling Rig

Hydrography Anchor Drilling Rig
Hydrography Anchor Drilling Rig Hydrography Anchor Drilling Rig

Large Image :  Hydrography Anchor Drilling Rig

Product Details:
Brand Name: MEGA DRILLTECH
Model Number: MDT-100
Payment & Shipping Terms:
Payment Terms: T/T, T/T
Contact Now

Hydrography Anchor Drilling Rig

Description
Highlight:

30m Anchor Drilling Rig

,

Hydrography Anchor Drilling Rig

,

Depth 40m Anchor Drilling Rig

Hydraulic anchoring drilling rig is mainly used in treating the disaster of landslide,rockslide so on,also used in rock anchoring,anchoring bar,strengthening retaining wll,supporting in deep foundation pit,mini-pile hole drilling,hydrography well drilling and high pressure jet-grouting for hydroelectric powerstation,communication,energy and capital construction.

Technical Specifications



drilling capacity hole dia Φ65mm,depth 40m
hole dia Φ130mm,depth 30m
pneumatic pressure(Mpa) 0.5~1.2
top-head speed(r/min) 35
top-head torque(N.m) 1027
max pull force(N) 24000
max feed force(N) 22000
max stroke(mm) 1200
angle range -90°~90°
overal dimension of drill body(L*W*H)mm/weight(kg) 2000×805×646/295
dimension of operation desk(L*W*H)mm/weight(kg) 636×430×700/25
Power unit(electric motor) model Y112M-4
power(kw) 4
speed(r/min) 1440
