Surface Mounted Core Drilling Rig

Surface Mounted Core Drilling Rig
Surface Mounted Core Drilling Rig

Large Image :  Surface Mounted Core Drilling Rig

Product Details:

Surface Mounted Core Drilling Rig

Description
High Light:

Hydraulic Core Drilling Rig

,

Surface Mounted Core Drilling Rig

,

160rpm Core Drilling Rig

Model MDT-300L MDT-300T
Borehole Diameter/ Depth BQ/400m; NQ/300m; HQ/100m
Drill Angle -90~0°
Drill Head Rotary Speed(FR/RE) 100~160rpm; 230~310rpm; 380~550rpm; 850~1100rpm
Max Output Torque of Drive Power Head 2200Nm
Drill Head Feeding Stroke 3500mm
Drill Head Max. Lifting Force 58KN
Drill Head Max. Thrust Force 40KN
  Max Lifting Ability 55KN
Main Winch (Lifting Drill Rod)
Hoisting Speed 0.45m/s
Assistant Winch (Wire-line Coring) Max Lifting Ability 1200KN
Hoisting Speed 2.45m/s
Mast Sliding Distance 800mm
Engine Model 4BT3.9-C100
Engine Power 74KW/2200rpm
Chassis Model Crawler type Trailer-mounted (MDT-300)T
(MDT-300)L
Overall Dimension(Drill Reduce Type) 5600×2200×2400
Drilling Rig Weight,appx. 5500kg 3500kg
