| Stroke: | 70 | Cylinder Diameter: | 70 |
|---|---|---|---|
| Power: | 7.5 | Shape Size: | 1925*795*1150(Diesel Engine)1840*795*995(Motor) |
| Weight: | 562(Motor) 630(Diesel Engine) | ||
| Highlight: | triplex piston slurry pumps,Reciprocating piston slurry pumps,Reciprocating Drilling Mud Pump |
||
MDT-150 mud pump is a horizontal reciprocating single-acting triplex piston pump with eight kinds of pressure and discharge available for use. This mud water pump is commonly applied to deliver drilling fluids into drill hole in the drilling engineering of geology, and it is fit for diamond drilling with small aperture and a maximum depth of 1500m. It is also perfect for middle and low pressure cement slurry perfusing.
With long service life of high wear parts, small volume, light weight, easy assembly and disassembly, this mud water pump enjoys stable performance.
| MDT-150 MUD PUMP | |
| Type | Horizontal, triplex, reciprocating, single acting piston pump |
| Stroke | 70mm |
| Bore | 70mm |
| Pump speed (s.p.m) | 222,130,86,57,183,107,71,47 |
| Output volume (l.p.m) | 150,90,58,38,125,72,47,32 |
| Discharge pressure (Mpa) | 1.8,3.2,4.8,7.0,2.3,4.0,6.0,7.0 |
| Volumetric efficiency | 85% |
| Input power (Kw) | 7.5 |
| Suction pipe dia (mm) | 51 |
| Discharge pipe dia (mm) | 32 |
| Drilling hole depth (m) | Diamond core drilling < 1500 |
| Overall dimensions (mm) | 1840*795*995(with motor) |
| Weight (kg) | 516(with motor) |
